Model R16

Handcrafted in Maine USA. Starting at $2650. Ships in a Mono Vertigo case. To inquire about a custom build, contact me here.

Standard Specs and Options:

Body Size
- Standard 13 1/2” wide body (about the size of a Les Paul)
- Jumbo 15 1/2” wide body +$350 (about the size of an ES-335)

Body Construction
- Solid body
- Semi-hollow body with f-hole +$250

Body Thickness
- 1 3/4”

Body Wood
- Mahogany

Body Top Wood
- Mahogany
- Roasted flame maple +$250
- Old growth figured redwood +$250
- Claro walnut +$250
- Myrtlewood +$250

Body Binding
- Black/Cream

Neck Joint
- Set neck

Truss Rod
- 2-way with access at headstock

Neck Wood
- One piece mahogany

Neck Carve
- Slim C Profile: 0.800" at first fret. 0.850" at 12th fret.
- Medium C Profile: 0.830" at first fret. 0.930" at 12th fret.
- 59' C Profile: 0.860" at first fret. 0.960" at 12th fret.
- Extra Fat C Profile: 1.00" at first fret. 1.00" at 12th fret.

Fretboard Wood
- Indian Rosewood

Fretboard Radius
- 12"

Nut Width
- 1.70" with 1.408” E to E string spacing

Nut Material
- White GraphTech Tusq XL

Fretboard End Width
- 2.50”

Scale Length
- 24.75"
- 25.5”

Number Of Frets
- 22

Headstock Pitch
- 7 Degrees

Finish
- Satin linseed oil based varnish with hand dyed sunburst top and hand dyed transparent black neck and body.

Tuning Keys
- Grover 133 Series Vintage Deluxe

Bridge
- Tonepros Tune-O-Matic with Stop Tailpiece
- Tonepros Tune-O-Matic with Trapeze Tailpiece
- Tonepros Adjustable Wraparound
- Tonepros Tune-O-Matic with Bigsby Vibrato +$250

Pickups
- TV Jones Classic FilterTrons are standard, or your choice of any pickups from TV Jones or McNelly. Two pickups covered in base price. Add $200 for a third pickup. Subtract $200 for a single pickup guitar.

Controls
- 1 master volume control and 2 tone controls. Centralab .033 uF oil filled tone capacitors. CTS and Switchcraft pots/switches. Inquire for other wiring requests.

Fretwire
- Jescar FW47095 (.047" wide .095″ tall)

Inlay
- 3/32" face dots. 1/16" side dots.

Case
- Mono Vertigo case included

Shipping
- Standard shipping price within USA $100
- International shipping price determined by country
